Encercle Draft TR2

TR2 uses a downward-pointing triangular frame, directing the eye toward information below the label. TR2 is the open outlined marker; TR2 Bold is its filled inverse counterpart with light lettering, not merely a heavier version.

Use TR2 for basement references, floor depressions, drainage points, and excavation depths on foundation plans or site sections. It suits searches for down-triangle plan labels, below-grade annotation fonts, and editable drainage markers.
