Encercle Draft CDI Bold

CDI combines a circular label field with four projecting diamond points, creating a distinctive hybrid frame. Its base treatment is the lighter outlined counterpart; CDI Bold reverses figure and ground into a filled inverse marker rather than simply adding weight.

Use CDI for material-reference callouts, finish-system codes, and keyed detail references on annotated elevations, where the compound silhouette can distinguish layered specifications from ordinary notes. It suits searches for circle-in-diamond markers and distinctive architectural detail symbols.
